DIGI-88B Command Protocol
Important Note: Be sure to include a carriage return after the command line when the command includes the “” suffix.
Also, there is a space between “cir” and the code, which is required.
RS232, RS485, and TCP/IP Routing Commands
Output 1 Commands
Function Command Response
Select Input 1 cir00 s11 The updated status for output 1. Represented as an
ASCII string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Etc….
Select Input 2 cir01 s12
Select Input 3 cir02 s13
Select Input 4 cir03 s14
Select Input 5 cir04 s15
Select Input 6 cir05 s16
Select Input 7 cir06 s17
Select Input 8 cir07 s18
Select Input Down cir08 new route
Select Input Up cir09 new route
Output 2 Commands
Function Command Response
Select Input 1 cir10 s21 The updated status for output 2. Represented as an
ASCII string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Etc….
Select Input 2 cir11 s22
Select Input 3 cir12 s23
Select Input 4 cir13 s24
Select Input 5 cir14 s25
Select Input 6 cir15 s26
Select Input 7 cir16 s27
Select Input 8 cir17 s28
Select Input Down cir18 new route
Select Input Up cir19 new route
Output 3 Commands
Function Command Response
Select Input 1 cir20 s31 The updated status for output 3. Represented as an
ASCII string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Etc….
Select Input 2 cir21 s32
Select Input 3 cir22 s33
Select Input 4 cir23 s34
Select Input 5 cir24 s35
Select Input 6 cir25 s36
Select Input 7 cir26 s37
Select Input 8 cir27 s38
Select Input Down cir28 new route
Select Input Up cir29 new route
Output 4 Commands
Function Command Response
Select Input 1 cir30 s41 The updated status for output 4. Represented as an
ASCII string in the format of “sXY” where:
• X is the output channel
• The value of Y maps as follows:
0 = input 1
1 = input 2
2 = input 3
3 = input 4
Etc….
Select Input 2 cir31 s42
Select Input 3 cir32 s43
Select Input 4 cir33 s44
Select Input 5 cir34 s45
Select Input 6 cir35 s46
Select Input 7 cir36 s47
Select Input 8 cir37 s48
