FLX-8X8A Installation Guide
24
Technical Specifications
FLX-8X8A Chassis
I/O Connections
Supported Input Cards
FLX-BI4, FLX-DI4, FLX-HI4, FLX-RI4
Supported Output Cards FLX-BO4, FLX-DO4, FLX-HO4
Input and Output Card Securing
Mechanism Thumb Screw
Analog Audio Input Eight (8) 3.5 mm, 5 pole Euroblock Connectors
Analog Audio Output Eight (8) 3.5 mm, 5 pole Euroblock Connectors
Control, Rear Panel RS232 via DE-9, TCP/IP via RJ45
Control, Front Panel Push Button, IR
Analog Audio
Performance per Channel
Balanced or Unbalanced Stereo Audio (20 Hz to 20
kHz)
Pinout (Left to Right) Left (+), Left (-), Ground, Right (+), Right (-)
Input Impedance >10KΩ
Output Impedance 50Ω
Frequency Response 20 Hz to 20 kHz, ±0.5 dB
Common Mode Rejection Ratio >90dB at 20 Hz to 20 kHz
Crosstalk >80 dB at 1 kHz
THD + Noise 1% at 1 kHz, 0.3% at 20 kHz
Chassis and Environmental
Internal Power Supply Rating
110-240 VAC, 50/60 Hz at 50 W
Material Black Painted Aluminum
Dimensions 88 mm x 444.5 mm x 320 mm (3.47 in. x 17.5 in. x 12.6
in.) (2RU)
Shipping Weight 6.26 kg (13.8 lbs.)
Operating Temperature 0° to +40° C (+32° to +104° F)
Operating Humidity 20% to 90%, Non-condensing
Storage Temperature -10° to +60° C (+14° to +140° F)
Storage Humidity 20% to 90%, Non-condensing
Other
Warranty
2 years
What’s in the Box FLX-8X8A (1 ea), Modular Metal Blank (4 ea), Rubber
Feet (4 ea), Power Cable (1 ea), RS232 Cable (1 ea),
Infrared Remote Control (1 ea), FLX-8X8A Installation
and Operation Guide (1 ea), Intelix Pocket Screwdriver
(1 ea)
