FLX-8X8A Installation Guide
20
RS232 and TCP/IP Commands
RS232 Settings: 9600 baud, 8 Data bits, 1 Stop bit, Parity = None
TCP/IP Settings: User defined IP address, port 4001
There is either a period (.) or a semicolon (;) at the end of each command. These characters must be
present for the command to process correctly.
There are no spaces between any of the characters in the command string.
Video and Audio Routing Commands
[X]All.
Route Video and Audio from input [X] to all outputs
All#. Route Video and Audio from each input to its corresponding output
All$. Turn off all Video and Audio outputs
[Y]$. Turn off Video and Audio for output [Y]
[X]B[Y]. Route Video and Audio from input [X] to output [Y]
[X]B[Y1],[Y2]. Route Video and Audio from input [X] to outputs [Y1], [Y2]
Number of outputs is unlimited; each output must be separated by a
comma (,)
Examples:
2All.
Route Video and Audio from input 2 to all outputs
4$. Turn off Video and Audio for output 4
6B3. Route Video and Audio from input 6 to output 3
3B2,8. Route Video and Audio from input 3 to outputs 2 and 8
Video Only Routing Commands
[X]V[Y].
Route Video from input [X] to output [Y]
[X]V[Y1],[Y2]. Route Video from input [X] to outputs [Y1], [Y2]
Number of outputs is unlimited; each output must be separated by a
comma (,)
Examples:
6V3.
Route Video from input 6 to output 3
3V2,8. Route Video from input 3 to outputs 2 and 8
