tina84e1 (2014-07) 25
• the digital input "Remote Zero" (briefly apply the
supply voltage to pin 10),
• an INFICON Vacuum Gauge Controller (VGC series).
While the gauge is being heated and/or under atmos-
pheric pressure, the zeroing function is locked in order
for operating errors to be prevented.

Evacuate the gauge to a pressure according to the table
below:
F.S.
Recommended final pressure for
zero adjustment
1100 mbar
1000 Torr
500 Torr/mbar
200 Torr/mbar
100 Torr/mbar
50 Torr/mbar
20 Torr/mbar
10 Torr/mbar
5
Torr/mbar
2 Torr/mbar
1 Torr/mbar
0.5 Torr/mbar
0.25 Torr/mbar
0.1 Torr/mbar
0.05 Torr/mbar
0.02 Torr/mbar
0.01 Torr
−
<5×10
-2 Torr
<2.5×10
-2
Torr
<10 -2 Torr
<5×10
-3
Torr
<2.5×10 -3 Torr
<10
-3
Torr
<5×10 -4 Torr
<2.5×10
-4
Torr
<10 -4 Torr
<5×10
-5
Torr
<2.5×10 -5 Torr
<10
-5
Torr
<5×10 -6 Torr
<2.5×10
-6
Torr
<10 -6 Torr
<5×10
-7
Torr
<6.65×10
0
Pa
<6.65×10 0 Pa
<3.33×10
0
Pa
<1.33×10 -0 Pa
<6.65×10
-1
Pa
<3.33×10 -1 Pa
<1.33×10
-1
Pa
<6.65×10 -2 Pa
<3.33×10
-2
Pa
<1.33×10 -2 Pa
<6.65×10
-3
Pa
<3.33×10 -3 Pa
<1.33×10
-3
Pa
<6.65×10 -4 Pa
<3.33×10
-4
Pa
<1.33×10 -4 Pa
<6.65×10
-5
Pa
<6.65×10
-2
mbar
−
<3.33×10
-2
mbar
<1.33×10 -2 mbar
<6.65×10
-3
mbar
<3.33×10 -3 mbar
<1.33×<10
-3
mbar
<6.65×10 -4 mbar
<3.33×10
-4
mbar
<1.33×10 -4 mbar
<6.65×10
-5
mbar
<3.33×10 -5 mbar
<1.33×10
-5
mbar
<6.65×10 -6 mbar
<3.33×10
-6
mbar
<1.33×10 -6 mbar
−
If the final pressure is too high for zero adjustment (>25%
of the F.S.), the zero cannot be reached and the
LED blinks green. If this is the case, activate
the factory setting and adjust the zero again (
→  34).

Operate the gauge for at least 2 hours (until the signal is
stable).
