Electrical connection 15-pin D-Sub, male
Sensor cable 15-pin plus shielding
Cable length
Supply voltage 15 V
≤ 8 m (0.14 mm²/conductor)
≤15 m (0.25 mm²/conductor)
Supply voltage 24 V ≤43 m (0.14 mm²/conductor)
≤75 m (0.25 mm²/conductor)
Supply voltage 30 V ≤88 m (0.14 mm²/conductor)
≤135 m (0.25 mm²/conductor)
For longer cables, larger conductor cross-sections are required
(R
cable
≤1.0 Ω).
Grounding concept → "Power Connection"
Materials exposed to vacuum ceramics (Al
2
O
3
≥99.5%),
stainless steel AISI 316L
Internal volume ≤4.2 cm 3
Admissible pressure (absolute)
1000 / 1100 F.S.
1 … 500 F.S.
0.01 … 0.5 F.S.
3 bar
2.6 bar
1.3 bar
Bursting pressure (absolute) 6 bar
Admissible temperatures
Storage
Operation
Bakeout –20 °C … +85 °C
+10 °C … +40 °C
≤110 °C at the flange
Relative humidity ≤80% at temperatures
≤+31 °C, decreasing to 50%
at +40°C
Use indoors only, altitude up to
3000 m NN
Degree of protection IP 30
Mounting orientation
0.01 … 0.05 F.S.
0.1 … 1100 F.S.
standing upright
standing upright to horizon-
tal
