12 Description
6 - FUSE and DIP switch S1, S2
Fuses for digital outputs and DIP switches (under the cover)
Fuses for digital outputs 1 ... 4 and 5 ... 8:
2 x 0.75 A (Schurter: 7010.9800.xx)
1 = ON, 0 = OFF, – = not used
1 = ON, + = switching OFF -> ON in operation, – = not used, x = no meaning
7 - LD
Connection for the data cable to the mass spectrometer module
8 - ANALOG IN
Analog input (input voltage range 0 V to 10.8 V)
Connection plug arrangement
DIP switch S1 4321
Factory setting
(default value of the interface protocol by MS module/control unit)
-000
ASCII protocol -010
LD protocol -011
Binary protocol -101
LDS1000 protocol -110
DIP switch S2 4321
Activate boot mode for software update x+––
Disable bus terminator 120 Ω for RS-485 1x––
1 24V supply (output)
2 GND to 24V supply
3 Analog input (0 V to 10.8 V)
4 GND to analog input
