INCRA T-Track Single Track - Manual

Mounting Options:
Use the supplied #8 x 1 ⁄ 2 ”
pan phillips wood screws to
mount your track using one
of the following options:
T-TRACK +
®
Manufactured by:
Taylor Design Group, Inc.
P.O. Box 810262
Dallas, TX 75381
Web Site: www.incra.com
Workbench
■ Use T-track in
your workbench
top to easily
locate your
favorite
clamping fixture.
Jigs & Fixtures
■ Use T-track to
position a hold-
down to specialty
jigs and fixtures.
Drill Press
■ T-track in your
drill press table
lets you position
and lock down
the fence as
well as clamping
fixtures. T-track
in the fence
locates and locks
a stop positioner
in place.
Applications:
Attach stops, guards, jigs, fixtures and hold-downs.
Use your INCRA T-track on the workbench or drill press.
Upgrade your
Miter Gauge
Fence
■ Front-mounted
T-track lets
you position a
stop, while rear-
mounted track
lets you slide
fence left or right
on your miter
gauge.
INCRA products are protected by one or more of the
following U.S. Patents: #4,793,604, #4,930,221, #5,195,730
#5,275,074, #5,423,360 #5,716,045 #6,237,457.
Other patents granted or pending.
INCRA is a registered trademark of Taylor Design Group, Inc.
© 2001 Taylor Design Group, Inc.
T-TRACK +
®
Surface
Mount
Use the supplied
fasteners to attach
to your application.
1
Flush Mount
A. Groove
Cut a groove
1 ⁄ 2 ” deep by
3 ⁄ 33 4 ⁄⁄ ” wide to
accept the
track.
2
B. Build-up
Use 1 ⁄ 2 ” thick
material on
either side
of a surface-
mounted track
to create a
flush mount.
