Instruction Manual HYDACLab ® 03.03.2008
9
9. Ordering Information
HLB 1 0 0 8 - 1 C - 00X - F 1
Serial number, factory set
Type of connection, mechanical
0 = G 3/4 A DIN 3852
Type of connection, electrical
8 = M12X1, 5 pole (mating connector not supplied)
Type of signal, output 1
1 = NC switching signal
Type of signal, output 2
C = analogue output 4 .. 20 mA, for output to a 3-conductor line
Modification number
000 = standard (pre-set, fixed)
001 = programmable
Seal material (parts in contact with the fluid)
F = FPM seal
Material of connection (parts in contact with the fluid)
1 = stainless steel
10. Dimensions
A
ppliance pl
ug
5 pole
, M12
x1
Hex AF 32
