1. Introduction
If you have any questions regarding the technical data or suitability of the product for your
applications, please contact our
Technical Sales Dept. HYDACLab ® sensors have been
individually calibrated on computerized testing stations and subjected to final testing and operate
perfectly when used according to the specifications (see Section 8. “Technical Data”).
If any problems should nevertheless, arise, please contact
HYDAC Service . Unauthorized
interference with the equipment will invalidate all warranty claims.
2. Safety instructions
The Fluid Condition Sensor HYDACLab ® presents no safety concerns when operated in
accordance with this user manual. However, in order to avoid any risk to the operator or any
damage due to incorrect handling of the unit, please note the following safety instructions:
Before commissioning, check that the unit is in perfect condition.
Before commissioning, please read the operating instructions. Ensure that the unit is
suitable for your application.
During transportation, extra care must be taken to protect the unit from vibration and shock.
The HYDACLab
®
must not be put into service if any known defects, either electrical or
mechanical, are apparent.
The unit must be installed exactly according to the instructions.
Read the information on the type code label.
Fault investigation and repairs must only be carried out by our customer service department
HYDAC Service.
All relevant and generally recognised safety requirements must be adhered to.
If the unit is not handled correctly, or if the operating instructions and specifications are not
adhered to, damage to the product or to personal injury may result.
3. Installation
The sensor can be installed directly in the hydraulic system via the threaded connection. It is
recommended that the sensor is mounted vertically with the electrical connector pointing
downwards. When fitting, ensure that the sensor is completely submerged in the fluid and that the
fluid can circulate freely around the sensor.
HYDAC ELECTRONIC provides appropriate installation accessories for installing the HYDACLab
®
(see Section 11.1, Accessories, Mechanical).
The electrical connection must be carried out by a qualified electrician according to the relevant
regulations of the country concerned (VDE 0100 in Germany).
HYDACLab
® Sensors carry the CE mark. A certificate of conformity will be provided on request .
EMC standards: EN 61000-6-1, EN 61000-6-2, EN 61000-6-3 and EN 61000-6-4 have all been
met. However, the stipulations of those standards will be met only if the sensor’s housing has been
correctly earthed by a qualified electrician. When fitted into a hydraulic block, it is sufficient if the
block is earthed via the hydraulic system.
Additional installation instructions that, from experience, reduce the effect of electromagnetic
interference are:
• Keep line connections as short as possible.
• Use screened wires, such as LIYCY 5 x 0.5 mm², only.
• The cable screening must be fitted by qualified personnel subject to the ambient conditions and
with the aim of suppressing interference.
• Keep the unit well away from the electrical supply of power equipment, as well as from
any electrical or electronic equipment causing interference.
