Instruction Manual HYDACLab ® 03.03.2008
16
13.1.3 Output 2
At this menu point, output 2 can be configured as a switching or analogue output. In
addition it is possible to read out all measured variables sequentially using the analogue
output.
• Analogue output
See description of the analogue output for output 1.
• Switching output
See description of the analogue output for output 1.
• Sequence output
With analogue output 2 it is possible to output the variables for temperature, relative
change in viscosity, relative change in dielectric constant (DC), relative humidity and the
status of the sensor sequentially. For this, under the "Sequence" menu, output 2 is
configured as current or voltage output. Press the "Activate" button to activate or
deactivate the sequence output. Press the "Ok" button to save the changed data in the
sensor and then return to the main menu. Press the "Cancel" button to discard the entries
and return to the menu of analogue output 2 (for more detailed explanation of the readout
of sequential analogue output, see Section 4.2).
13.1.4 Restarting the System
Under this menu point, the sensor is forced to restart after every change in sensor
parameter. Only then will all the changed settings for analogue and switching outputs be
adopted.
The stored data including the referencing phase are retained during a system restart.
Press "Ok" to carry out a restart. Press "Cancel" to return to the main menu. The error
message which appears can be ignored. After approx. 2 seconds you can return to the
main menu after pressing "Cancel".
14. Items supplied
1 HYDACLab
®
Sensor
1 Operating Manual
