6.1.3 Meanings of the LEDs
Power:
The head is powered up.
RX-OK:
Received beam is good for communication
TP Lk:
Copper link between the head and the Network
FO Lk:
The recived signal form the remote end is modulated and
R-V/TP:
Remote end is visible for the management system and there is TP connected to
remote end – same as TP-Lk but displays it on the remote end.
Top Level LEDs:
Local Received level
Bottom Level LEDs:
Remote Sites Received level
10
th
LED:
The 10 th LED has three functions showing that the recived level reached its
optimum this is green, it maximum it
is red
