Attaching the G1 dock to the Keyboard Mount
1. Attach the G1 dock to the Keyboard mount as shown below with the hardware
supplied with the docking station. A Gamber-Johnson clevis could also be attached to
the back side of the keyboard mount at this same location.
Mounting the Keyboard Mount in a vehicle
The keyboard mount has 1/4-20 threaded inserts on the bottom side for mounting to
Gamber-Johnson motion attachments. Attach with the 1/4-20 x 1/2" long socket button
head screws found in the hardware bag.
The mount also has a clearance hole for a 3/8" bolt and (3) .281 square holes that will
align with the smiley face pattern on Gamber-Johnson upper poles. Hardware has not
been included for these optional mounting locations.
1/4-20 threaded inserts
.281 square holes
hole for 3/8" bolt
