Gamber-Johnson 7160-0452 - Manual (Page 2)

2/3
Figure 1.
MOTION ATTACHMENT
ASSEMBLY
3/8" Flat Washer
and Nylok Nut
bearing, bearing backup plate and 3/8" flat washer over the stud. Apply thread
Figure 1.)
locker to the stud and tighten the nylok nut until the desired friction is obtained. (See
CENTER UPPER TOP
CENTER UPPER BOTTOM
the 3/8" stud. Next place the motion attachment over the stud. Place the remaining
Flat Washers
1/4" Bolts and
Mongoose Locking Slide Arm. To attach, place one of the bearing backup plates on
and Nylok Nuts
1/4" Flat Washers
Backup Plate
Steel Bearing
Attaching a Motion Attachment to the Mongoose Locking Slide Arm 7160-0397, 7160-
0427, 7160-0452
Various Motion Attachments with a .38" mounting hole can be added to the
Nylon Bearing
MONGOOSE LOCKING
SLIDE ARM
