ASSEMBLY INSTRUCTIONS FOR OL5601, OL5603, OL5604
Bulb
(not included)
Candle Tube
Socket
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Top Cover
Fixture Plate
Threaded Stud
Finial
Main Frame
Finial
Carefully unpack and identify all parts
before assembly. Bulb is not included.
1. Install finial by screwing onto top cover.
2. Follow enclosed “Standard Outdoor
mounting Plate installation instructions”
for electrical and fixture installation onto
wall outlet box.
3. Slip candle cover tube onto sockets.
4. Install light bulb (not included). See
relamping label at socket area for type and
maximum allowed wattage.
5. Slide main frame up until it checks inside
of top cover. Lock them into position with
finial.
