Feiss WB1704 User Manual
Urban renewal 2 light wall, Installation instructions for, Wall wb1704
1
Installation Instructions for
Urban Renewal 2 Light Wall
1.0
WB1704
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Wall
WB1704_
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
Install the shade by placing it over the socket, then using the washers and thumb screws to secure it.
1
2
1A
1
LAMP
WASHER
SHADE
3
3
THUMB SCREW
SOCKET
1
2
