Feiss OL9506 User Manual
Wembley park 3 light outdoor wall lantern, Installation instructions for, Use minimum 90°c supply conductors
1
Installation Instructions for
Wembley Park 3 Light Outdoor Wall Lantern
1.1
OL9502-O 9504-OL9506
L
Outdoor
O 9502, O 9504,
L
L
O 9506_
L
_
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is listed by one of the following
“ ationally
ecognized
esting aboratory”
N
R
T
L
This product is suitable for wet locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Install the candle tubes by slipping them through the sockets.
Screw the lamps into the sockets. Refer to the label on the lamp socket for Max Wattage information.
Screw the threaded pipe to the coupler.
Place the shade and decorative cup over the threaded pipe and secure them in place by tightening the finial.
1
2
1A
LAMP
3
4
SHADE
SOCKET
1
4
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
THREADED PIPE
FINIAL
DECORATIVE CUP
4
3
COUPLER
CANDLE TUBE
5
2
HEX NUT
