Feiss OL9311 User Manual
Mc coy 1 light outdoor lantern, Installation instructions for, Ol9311

1
Installation Instructions for
Mc Coy 1 Light Outdoor Lantern
1.0
OL9311_
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
OL9311_
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for wet locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1A
3
Outdoor
4
SHADE
SET SCREW
LAMP
2
BASE SCREW
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Place the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
Place the shade into the fixture base and assemble with fixture top.
Secure the assembly by first installing and tightening the bottom fixture screws, then by installing and tightening the top
set screws.
1
2
3
4
FIXTURE BASE
4
4
FIXTURE TOP
3
1
1
