Feiss P1295 - Manual

1
Installation Instructions for
Parkman 1 Light Pendant
1.0
P1295
Pendant
P1295_
G P I : ENERAL RODUCT NFORMATION
This product is listed by one of the following
“ ationally
ecognized esting aboratory” N R T L
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Screw a nut onto one end of the threaded pipe, then place the shade and a washer over the other end of the threaded
pipe and secure them together by tightening with the other nut.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
Install the shade to the socket assembly and secure it in place by using the thumb screws.
Place the decorative cup over the threaded pipe and secure them in place by tightening the finial.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
1
2
1A
LAMP
5
SOCKET ASSEMBLY
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
SHADE
1
THUMB SCREW
2
NUT
WASHER
NUT
WASHER
FINIAL
DECORATIVE CUP
3
4
5
3
4
THREADED PIPE
3
