Feiss P1316 User Manual
Dutch 1 light pendant, Installation instructions for, Use minimum 90°c supply conductors
1
Installation Instructions for
Dutch 1 Light Pendant
1.0
P1297-P1298-P1316
Pendant
P1297, P1298, P1316_
Determine the wanted height of the fixture by feeding the cord through the canopy and moving the cord up or down.
Place the cord in between the two cord clips and secure it in place using the clip screws.
Trim the cord leaving enough for electrical connections. From the end of the cord, strip the insulation 4” and then strip the
end of the wires. Note: Make sure not to nick the inner wires.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
1
2
1A
LAMP
FIXTURE
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is listed by one of the following
“ ationally
ecognized
esting aboratory”
N
R
T
L
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
CORD
CANOPY
CORD CLIP
CLIP SCREW
2
3
4
5
5
4
