1
Installation Instructions for
Denmark 1 Light Pendant
1.0
F2792-1
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Pendant
F2792_
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Secure the mounting plate to the electrical box with the two provided mounting plate screws.
Connect the fixture ground wire to a suitable ground in accordance to local electrical codes.
Connect the white fixture wire to the neutral power line wire with a wire nut.
Connect the black fixture wire to the hot power line wire with a wire nut.
Secure the canopy to the mounting plate with the two provided canopy screws.
Install shade by fastening with counter ring.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
1
2
3
1A
COUNTER RING
SHADE
4
5
7
MOUNTING
PLATE SCREW
MOUNTING PLATE
CANOPY SCREW
CANOPY
6
1
5
6
7
6
HOT WIRE
NEUTRAL WIRE
WHITE WIRE
BLACK WIRE
