Assembly Instructions For
1
1
4
5
7
3
8
2
F2746/6
(E) 5/2012
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts
before assembly. Bulbs not included.
1. Spread open the fixture arms so they are
evenly spaced from each other.
2. Slip the top of the center pipe through
the top section of the upper arms. Then
install by screwing the center pipe onto
the socket assembly.
3. Install top and bottom arms together and
secure using the ball cap nut.
4. Install the fixture loop and cap onto the
top of the fixture.
5. Install the bottom assembly onto the
bottom of the fixture and secure using
the finial.
6. A. Install the candle follower onto the
candle tube.
B. Install light bulb (not included). See
relamping label at socket area for type
and maximum allowed wattage.
7. Hang all decorative parts as shown on
drawing.
NOTE: Replace broken drop or pin by
gently bending open the pin, remove the
broken drop or pin, hook new the one,
then close back the pin. Avoid bending
the pin into a sharp angle.
8. Follow enclosed supplement installation
instructions for electrical and fixture
installation onto house outlet box. If you
do not have an outlet box at desired
location to attach the fixture then hire a
qualified electrician to create one.
6A
6B
GND
