Installation Instructions for
Marcia 5 Light Chandelier
1.0
F2804-5
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Chandelier
F2804-5_
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Install the candle tube by slipping through the socket.
Install the candle follower on top of the candle tube.
Install the lamp by screwing it into the socket. Refer to the label on the lamp socket for Max Wattage information.
Install the stem and spacer onto the socket assembly by screwing them to the threaded nipple.
Install and secure the string of beads by hooking them to the top and bottom of the fixture as shown on drawing.
Install the font by hooking the support chains to the bottom of the fixture and to the font, then hook the lower string of beads to the font.
Install the jewels by hanging them as shown on drawing.
Install the fixture to the chain by placing the fixture top over the fixture loop, then opening the bottom chain link and securing it to the fixture
loop by closing the link.
BOTTOM
TOP
1A
7
1
2
6
9
5
LAMP
FIXTURE
CHAIN LINK
STEM
FIXTURE LOOP
FIXTURE TOP
FONT
SUPPORT CHAIN
STRING OF BEADS
STRING OF BEADS
JEWEL
1
2
3
4
5
6
7
8
9
CANDLE FOLLOWER
CANDLE TUBE
3
4
SPACER
THREADED NIPPLE
6
8
8
9
