1
Installation Instructions for
Hugo 6 Light Chandelier
1.0
F2901-6
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Chandelier
F2901-6_
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry indoor locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1A
SHADE
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Determine desired width of extendable arms, then loosen and tighten screws as needed.
Screw the stem, spacer, ball and fixture loop to the threaded pipe as shown, then screw the threaded pipe to the fixture.
Install candle tube by slipping through socket.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
Place and secure shade over lamp.
Open chain link and secure it to the fixture loop by closing the link.
1
2
3
LAMP
CANDLE TUBE
4
4
5
3
2
7
SCREW
1
3
5
6
6
7
7
THREADED PIPE
STEM
FIXTURE LOOP
BALL
SPACER
CHAIN LINK
EXTENDABLE ARMS
