Feiss F2745 User Manual
Assembly instructions for
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts
before
assembly. Bulbs not included.
1. Install the fixture loop onto the top of the
fixture.
2. Follow enclosed supplement installation
instructions for electrical and fixture
installation onto house outlet box. If you
do not have an outlet box at desired
location to attach the fixture then hire a
qualified electrician to create one.
3. Install light bulb (not included). See
relamping label at socket area for type
and maximum allowed wattage.
4. Install the threaded pipe onto the socket
assembly as shown.
5. Raise the glass plate and slip it through
the installed threaded pipe. Secure the
glass plate with the washers and hex nut.
6. Then place the cover onto the threaded
pipe below the glass plate and fasten it
into place using the finial.
Assembly Instructions For
2
3
4
5
6
1
F2745/4
(E) 11/11
