1
Installation Instructions for
Lismore 9 Light Chandelier
1.0
F2937-3-6
Chandelier
F2937/3+6_
G P I : ENERAL RODUCT NFORMATION
This product is listed by one of the following
“ ationally
ecognized esting aboratory” N R T L
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Install the candle tube by slipping it through the socket.
Install the shade by placing it over the candle tube.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information. Repeat steps 1-3 for
remaining sockets.
Using the help of another person, connect the upper tier of the chandelier to the hub by hooking each fixture arm into the
corresponding hook.
Using the help of another person, connect the lower tier of the chandelier to the upper tier by hooking each fixture arm
into the corresponding hook.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
1
2
3
4
1A
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
LOWER TIER
3
5
5
LAMP
SOCKET
SHADE
4
1
HUB
CANDLE TUBE
FIXTURE ARM
5
4
5
UPPER TIER
6
4 4
5 5
2
