Installation Instructions for
Cumberland 9 Light Chandelier
1.0
F2822-3-6
F2822-3+6_
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Open the arms and spread them so that they are equally spaced apart.
Install the upper hub cover by placing it over the threaded pipe and securing it using the nut and fixture loop.
Install the lower hub cover by placing it over the threaded pipe and securing it using the cover nut.
Install ring onto the bottom of the sockets and secure it using the finials.
Install the shade by placing it over the socket and securing it with the collar nut.
Install the fixture to the chain by opening the quick link and securing it to the fixture by closing the link.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
1
2
3
4
5
1A
LAMP
SHADE
COLLAR NUT
SOCKET
UPPER HUB COVER
LOWER HUB COVER
THREADED PIPE
FINIAL
FIXTURE LOOP
6
COVER NUT
RING
7
1
5
8
6
4
3
7
QUICK LINK
8
NUT
Chandelier
G P I : ENERAL RODUCT NFORMATION
This product is listed by one of the following
“ ationally
ecognized esting aboratory” N R T L
This product is suitable for dry indoor locations only.
This product may be dimmed with a standard incandescent dimmer.
CAUTION - RISK OF FIRE
This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.
Use minimum 90°c supply conductors.
