IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE OR
CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before assembly.
Bulb not included.
1. Spread open arms so they are evenly spaced apart
from each other.
2. Install a hex nut onto bottom end of short threaded
pipe leaving about 3/8" (10mm) of thread exposed.
Slide short threaded pipe, cover, and fixture loop
through fixture wires. Screw the short threaded pipe
into coupler located at top of fixture. Tighten hex nut.
Then slip cover through the threaded pipe. Lock all
together by fastening the fixture loop onto protruding
threaded pipe.
3. Follow enclosed supplement installation instructions
for electrical and fixture installation onto house outlet
box. If you do not have an outlet box at desired
location to attach the fixture than hire a qualified
electrician to create one.
4. Place Shade over threaded socket then spacer tube and
secure with counter ring, using supplied wrench.
5. Install light bulbs (not included). See label located at
socket area for type and maximum allowed wattage.
Assembly Instructions For
F2252/5, F2254/6+6+3
Fixture Loop
Bulb
(not included)
Wrench
(supplied)
Spacer Tube
Counter Ring
Cover
Coupler
Short Threaded Pipe
Socket
Arm
Shade
1
2
5
4
3
(E) 10/07
