1
Installation Instructions for
Maarid 1 Light Chandelier
1.0
F2799-1
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Chandelier
F2799-1_
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry locations only.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1
2
1A
FINIAL SET
STRING OF BEADS
3
Secure the mounting plate to the electrical box with two mounting plate screws.
Install the lamp by screwing it into the socket. Refer to the label on the lamp socket for Max Wattage information.
Install and secure the string of beads by hooking them to the top and bottom of the fixture.
Determine desired finial, then screw the finial set to the bottom of the fixture.
Determine the desired height of the fixture and remove a portion of the chain by opening a link and removing it, then install the chain to
the fixture and canopy by opening the quick link and securing it to the fixture loop by closing the link.
Weave the cord through the chain (ensuring that the cord goes through the canopy) and trim the cord leaving enough to make electrical
connections.
Connect the fixture to a suitable ground in accordance to local electrical codes.
Connect the white fixture wire to the neutral power line with a wire nut.
Connect the black fixture wire to the hot power line wire with a wire nut.
Neatly place wires into the electrical box, then place the canopy onto the ceiling and secure it with canopy screws.
SEMI-FLUSH MOUNT
INSTALLATION
4
5
3
3
4
2
5
1
LAMP
FIXTURE
QUICK LINK
CANOPY
MOUNTING PLATE
MOUNTING
PLATE SCREW
CANOPY SCREW
BLACK WIRE WHITE WIRE
NEUTRAL WIRE HOT WIRE
CHAIN LINK
6
7
8
9
5
5
8 9
ASSISTANCE REQUIRED
This product may require assistance from another person
for installation and safety purposes.
10
10 10
