Assembly instructions for

Assembly Instructions For
F2569/3
(E) 2/11
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before
assembly. Bulbs not included.
1. Choose desired installation height from dimensions
shown in above diagram. Thread fixture wire
through each stem to be used. Please note correct
position of stems from left diagram. Screw all stems
together until secure.
2. Slip fixture loop through fixture wires, then install
by screwing on top of stems.
3. This fixture is supplied with threaded chain links.
The links are opened and closed by twisting
cylinder on chain link. The threaded chain link
should be installed onto the fixture loop and the
other should be installed onto the canopy loop.
4. Follow enclosed supplement installation instructions
for electrical and fixture installation onto house
outlet box. If you do not have an outlet box at
desired location to attach the fixture then hire a
qualified electrician to create one.
5. Install bulb (not included). See relamping label
located near socket area for type and maximum
allowed wattage.
6. Disassemble the shade from the frame by loosening
knob.
7. Place glass plate onto frame and secure with washer
and knob.
8. Place shade onto the frame and secure with the
knob.
(3) PCS. (11) PCS.
A
A
B
B
Note: Spare crystals (A) and Pin-links (B) enclosed in hardware bag.
