Feiss F2776-3 User Manual
Assembly instructions for
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE
OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts
before
assembly. Bulb not included.
1. Install the center pipe onto the top of the
socket assembly.
2. Thread the top stem into the steel plate
and canopy as shown and secure with the
washer and hext nut.
3. Follow enclosed supplement installation
instructions for electrical and fixture
installation onto house outlet box. If you
do not have an outlet box at desired
location to attach the fixture then hire a
qualified electrician to create one.
4. Install shade by fastening with counter
ring and spacer.
5. Install light bulb (not included). See
relamping label at socket area for type
and maximum allowed wattage.
Assembly Instructions For
3
2
5
4
1
F2776/3
(E) 5/2012
