Feiss F2691-4 - Manual

IMPORTANT
TURN OFF THE POWER AT THE MAIN
FUSE OR CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before
assembly. Bulbs not included.
1. Follow enclosed supplement installation
instructions for electrical and fixture installation
onto house outlet box. If you do not have an
outlet box at desired location to attach the
fixture then hire a qualified electrician to create
one.
2. Install the glass panels onto the fixture with the
thumb screws and washers as shown.
3. Install shade by fastening with counter ring and
spacer.
4. Install light bulb (not included). See relamping
label at socket area for type and maximum
allowed wattage.
Assembly Instructions For
F2691/4
(E) 5/11
1
3
4
2
24 - 7/8"
30 - 7/8"
36 - 7/8"
42 - 7/8"
48 - 7/8"
54-7/8"
60 - 7/8"
66-7/8"
72 - 7/8"
18- 7/8"
