1
Installation Instructions for
Luminary 3 Light Chandelier
1.0
F2802-3
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Chandelier
F2802-3_
G P I : ENERAL RODUCT NFORMATION
This product is suitable for dry locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
1
2
1A
FINIAL SET
CANDLE TUBE
FIXTURE BASE
SHADE
3
Depending on desired mounting (chain or semi-flush), follow enclosed supplement installation instructions for electrical
and fixture installation onto house outlet box.
Install the threaded stem to the fixture and fixture base by screwing them together.
Install the candle tube by slipping it through the socket.
Install the lamp by screwing it into the socket. Refer to the label on the lamp socket for Max Wattage information.
Install the shade by installing the decorative hooks to the spun pan with hook screws and insert the shade through the
spun pan, then hook the side arms to the hooks and decorative hooks.
Install finial set to the fixture base in the order shown by tightening it (Do not over tighten).
THREADED STEM
SEMI-FLUSH MOUNT INSTALLATION
1
LAMP
SIDE ARM
DECORATIVE HOOK
1
HOOK
FIXTURE
4
5
6
5
4
3
2
2
6
HOOK SCREW
5
SPUN PAN
5
