IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE OR
CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before assembly. Bulbs
not included.
1. Install glass panels: (see fig.1)
A. Gently grabbing onto a glass panel, slip inside of main
frame. Make certain bottom edge of panel sits inside of
bottom tabs.
B. Secure glass panel by bending tabs located at top.
C. Repeat rest panels.
2. Follow enclosed supplement installation instructions for
electrical and fixture installation onto house outlet box. If
you do not have an outlet box at desired location to attach
the fixture then hire a qualified electrician to create one.
3. Hook decorative chains first onto the column and then
proceed to hook onto loops located on top of main frame.
4. Install a hex nut onto one end of long threaded pipe leaving
about 3/8” (10 mm) thread exposed. Screw same end of
threaded pipe into bottom of socket assembly. Tighten hex
nut.
5. Install light bulb (not included). See relamping label at socket
area for type and maximum allowed wattage.
6. Slip glass plate through long threaded pipe until it checks
inside of main frame. Lock glass plate by fastening with finial.
Do not over tighten.
Assembly Instructions For
SF274
(E) 10/09
5
6
4
1
Fig. 1
3
2
