Feiss VS12701 User Manual
Assembly instructions for
(E) 10/07
IMPORTANT
TURN OFF THE POWER AT THE MAIN FUSE OR
CIRCUIT BREAKER BOX
BEFORE STARTING INSTALLATION
Carefully unpack and identify all parts before
assembly.
Bulbs not included.
1. Before proceeding below instructions followenclosed
“Multiple Standard InstallationInstructions” for
electrical and fixtureinstallation onto outlet box.
2. Remove counter ring and spacer tube from socket. Set
them aside.
3. Install glass shade onto fitter and lock into position by
installing the spacer tube and counter ring back onto
the socket. Use supplied wrench to tighten.
4. Install light bulb (not installed). See relamping label at
socket area for type and maximum allowed wattage.
Assembly Instructions For
VS12701
Bulb
(not included)
Fixture Plate
Shade
Spacer Tube
Socket
Fitter
Cap Nut
Counter Ring
Wrench
(supplied)
