Feiss WB1608 User Manual
Hugo 1 light wall, Installation instructions for, Wall wb1608
1
Installation Instructions for
Hugo 1 Light Wall
1.0
WB1608
CAUTION - RISK OF FIRE
This product requires installation by a qualified electrician.
Before installing be sure to read all instructions and
TURN THE POWER TO THE ELECTRICAL BOX OFF.
Wall
WB1608_
G
P
I
:
ENERAL
RODUCT NFORMATION
This product is suitable for damp locations.
This product may be dimmed with a standard incandescent dimmer.
This instruction shows a typical installation.
Follow enclosed supplement installation instructions for electrical and fixture installation onto house outlet box.
Determine desired width of extendable arm, then loosen and tighten screws as needed to set width.
Install candle tube by slipping through socket.
Screw the lamp into the socket. Refer to the label on the lamp socket for Max Wattage information.
Place and secure shade over the lamp.
1
2
1A
LAMP
CANDLE TUBE
SHADE
3
EXTENDABLE ARM
4
SCREW
5
1
2
3
4
5
