1 overview, 2 connection and setup of the evaluation unit cia3, 1 rs232-interface – EUCHNER CIS3A-Mini User Manual
Page 3: Cia3sx...g08 pc or sps
EUCHNER
Identsystem
CIS3A-Mini
084727-01-02/03
Subject to technical modification
Page 3 / 22
1 Overview
This manual describes technical features and function of the evaluation unit with serial
interface cat. no. 077910 type CIA3SX1R1G08 and the communication with PC or SPS.
The transfer telegrams for the commands
- Program (write) data carrier
- Read
data
carrier
are based on the 3964R transfer procedure [1].
2 Connection and setup of the evaluation unit CIA3...
2.1 RS232-Interface:
9 - pin
25 - pin
CIA3SX...G08
PC or SPS
