Byte
No. Description
ASCII
C o n t e n t s
hex
decimal
0 Number of telegram bytes 07 7
1
2 Command
identification T
L 54
4C 84
76
3 Read/write head address 01 1
4
5 Start address of
user data 00
00 0
0
6
Number of bytes of
user data
05 5
Figure 7: Command telegram "read data carrier read-only" (telegram core)
Byte
No. Description
ASCII
C o n t e n t s
hex
decimal
0 Number of telegram bytes 0C 12
1
2 Command
identification R
L 52
4C 82
76
3 Read/write head address 01 1
4
5 Start address of
user data 00
00 0
0
6
Number of bytes of
user data
05 5
7 ... 11 User data ASCII or hex resp. BCD (code-transparent)
Figure 8: Response telegram "read data carrier read-only" (telegram core)
Byte
No. Description
ASCII
C o n t e n t s
hex
decimal
0 Number of telegram bytes 07 7
1
2 Command
identification R
F 52
46 82
70
3 Read/write head address 01 1
4
5 Padding data 00
00 0
0
6 Status number **)
Figure 9: Response telegram "Read data carrier read-only (status)" (telegram core)
**) Status number 02
hex
Data carrier not in active area
(more status numbers see chapter 8)
