EUCHNER Identsystem CIS3A-Mini
084727-01-02/03 Subject to technical modification Page 12 / 22
4.1 Write operation
The data carrier must be in front of the read/write head in case of this command and
may be removed from the active range only after reception of the response telegram.
Please note:
It is only possible to work with a maximum of 32 bytes of user data per command
telegram! If more data is required (max. 116 byte), it must be splitted to more than one
command telegram.
Command telegram (telegram core, PLC ® CIA3SX , see also figure 2):
TP (read/write head address) (start address) (number of bytes user data) (user data)
Response telegram (telegram core, CIA3SX ® PLC, see also figure 3):
RF (read/write head address) (0,0) (status no.)
Byte
No. Description
ASCII
C o n t e n t s
hex
decimal
0 Number of telegram bytes 0B ... 7B 11 ... 123
1
2 Command
identification T
P 54
50 84
80
3 Read/write head address 01 1
4
5 Start address of the
user data 00
00 ... 70 0
0 ... 112
6
Number of bytes of the
user data
04 ... 20 4 ... 32
7 ... 122 User data ASCII or hex resp. BCD (code-transparent)
Figure 2: Command telegram "write data carrier" (telegram core)
Byte
No. Description
ASCII
C o n t e n t s
hex
decimal
0 Number of telegram bytes 07 7
1
2 Command
identification R
F 52
46 82
70
3 Read/write head address 01 1
4
5 Padding data 00
00 0
0
6 Status number **)
Figure 3: Response telegram "write data carrier" (telegram core)
**) Status number 00
hex
: No error
02
hex
: Data carrier not in active range
(more status numbers see chapter 8)
