Operating Instructions Safety Switch CES-AH-C03-AH-SM
23
Technical data for actuator CES-A-BRN
Parameter Value Unit
min. typ. max.
Housing material PPS
Dimensions 80 x 40 x 15 mm
Weight 0.06 kg
Ambient temperature - 25 - + 70 °C
Degree of protection acc. to EN
IEC 60529
IP67
Installation position Active face opposite read head
Power supply Inductive via read head
Dimension drawing
40
80
10,3
5,5
17
11
17
11
15
8,5
Active face
Active face
