Enerpac PR-Series Air User Manual
Page 2
2
RAISE
LOWER
7
1
15
3
18
19
16
13
5
8
9
7
12
4
10
11
2
14
20
Table 2 - Stroke Lengths and Weights
Short Stroke
Models
Stroke Length
Weight
Long Stroke
Models
Stroke Length
Weight
inches
mm
Pounds
Kg
inches
mm
Pounds
Kg
PRAMA06014L
14
356
390
177
PRAMA06027L
27
686
600
272
PRAMA10016L
16
406
510
231
PRAMA10027L
27
686
600
272
PRASA10016L
16
406
510
231
PRASA10027L
27
686
600
272
PRASA15016L
15.5
394
570
258
PRASA15027L
26.5
673
708
321
PRASA20016L
15.5
394
640
290
PRASA20027L
26.5
673
825
374
Note: Refer to Enerpac catalog for product external dimensions.
Figure 1, Major Features and Components - PRAMA Series Models
3.0 PRODUCT DATA
Table 1 - General Specifi cations
Maximum Operating Pressure
Model
psi
bar
PRAMA060_ _L
6,000
414
PRAMA100_ _L & PRASA100_ _L
9,700
669
PRASA150_ _L
10,200
703
PRASA200_ _L
10,200
703
Load Rating
Model
US Tons
Metric Tons
kN
PRAMA060_ _L
60
54
533
PRAMA100_ _L & PRASA100_ _L
100
90
889
PRASA150_ _L
150
136
1333
PRASA200_ _L
200
181
1778
Hydraulic Oil Type
Enerpac HF (Refer to Table 8 for oil specifi cations)
Maximum Hydraulic Oil Temperature
170 ºF [76 °C]
Hydraulic Reservoir Oil Capacity
(approximate - when fi lled to
proper level)
4.2 gallons [15,9 liters]
Air Requirements (minimum)
50 CFM @ 80 psi [1416 l/min @ 5,5 bar]
Key:
1. Handle Lock Lever
2. Handle Assembly
3. Lifting Bar
*
4. Air Supply Valve
5. Control Valve, Manual
7. Air Line Lubricator
8. Reservoir Air Breather
9. Air Line Filter/Regulator
10. Air Inlet Connection (1/2" NPT)
11. Oil Fill Plug
12. Oil Filter
13. Hydraulic Cylinder
14. Hydraulic Reservoir
15. Oil Drain Plug
16. Air Muffl
er
17. Lifting Eyebolt
*
18. Wheel Bearing Grease Fitting
19. Tire Air Valve
20. U-Ring Storage
*
Not present on all models.
17
