Chapter 2:
Product Description
This installation guide describes the Eagle HV servo drive and the steps for its wiring,
installation and power-up. Following these guidelines ensures optimal performance of the drive
and the system to which it is connected.
2.1. ExtrIQ Product Family
Elmo Motion Control’s ExtrIQ product family is a set of durable motion control products for
applications operating under extreme environmental conditions. The products are capable of
withstanding the following extreme conditions:
Feature
Operation Conditions Range
Ambient
Temperature
Range
Non-operating
conditions
-50 °C to +100 °C (-58 °F to 212 °F)
Operating conditions
-40 °C to +71 °C (-40 °F to 160 °F)
Temperature
Shock
Non-operating
conditions
-40 °C to +71 °C (-40 °F to 160 °F) within 3
min
Altitude
Non-operating
conditions
Unlimited
Operating conditions
-400 m to 12,000 m (-1312 to 39370 feet)
Humidity
Non-operating
conditions
Up to 95% non-condensing humidity at
35 °C (95 °F)
Operating conditions
Up to 95% non-condensing humidity at
25 °C (77 °F), up to 90% non-condensing
humidity t 42 °C (108 °F)
Vibration
Operating conditions
20 Hz to 2000 Hz, 14.6 g
Mechanical
Shock
Non-operating
conditions
±40g; Half sine, 11 msec
Operating conditions
±20g; Half sine, 11 msec
All ExtrIQ products have been tested using methods and procedures specified in a variety of
extended environmental conditions (EEC) standards including:
•
MIL-STD-704- Aircraft, Electric Power Characteristics
•
MIL-STD-810- Environmental Engineering Considerations and Laboratory Tests
•
MIL-STD-1275- Characteristics of 28 Volt DC Electrical Systems in Military Vehicles
•
MIL-STD-461- Requirements for the Control of Electromagnetic Interference Characteristics
of Subsystems and Equipment
