Drum HV (High Voltage) Installation Guide Technical Specifications
MAN-DRU-HVIG (Ver. 1.602)
www.elmomc.com
70
4.3. Power Ratings
Feature Units 50/400 R100/400 35/800 R70/800 R100/800
Minimum supply voltage VDC *For S suffix type = 50
For 0 or 1 suffix type = 100
*For S suffix type = 100
Nominal supply voltage VDC 325 560 for 400 VAC
680 for 480 VAC
Maximum supply voltage VDC 400 780
Maximum continuous power
output
kW 16 33 22 45 65
Efficiency at rated power (at
nominal conditions)
% > 98
Auxiliary supply option, for S drives VDC 18 to 30
Auxiliary power supply (external
option)
VA ≤3 VA without external loading
≤7 VA with full external loading
Continuous current limit (Ic)
amplitude of sinusoidal/DC
trapezoidal commutation
A 50 100 35 70 100
Sinusoidal continuous RMS current
limit (Ic)
A 35 71 25 50 71
Peak current limit A 100 No peak 70 No peak No peak
Weight kg (oz) 1.623 kg (57.25 oz)
Dimensions mm (in) 180 x 142 x 75.2 (7.08" x 5.59" x 2.96")
Digital in/Digital out/ Analog in
6/4/1
Mounting method Panel / Wall Mounted
*See page 18 for details on the part number. The S suffix appears in models where there is a
24 V control supply. If there is no S suffix, the control power supply operates from the main
power.
Note on current ratings: The current ratings of the Drum HV (High Voltage) are given in
units of DC amperes (ratings that are used for trapezoidal commutation or DC motors). The
RMS (sinusoidal commutation) value is the DC value divided by 1.41.
