2.4. How to Use this Guide
In order to install and operate the Drum HV (High Voltage) servo drive, you will use this manual
in conjunction with a set of Elmo documentation. Installation is your first step; after carefully
reading the safety instructions in the first chapter, the following chapters provide you with
installation instructions as follows:
•
Chapter 3 - Installation
, provides step-by-step instructions for unpacking, mounting,
connecting and powering up the Drum HV (High Voltage).
•
Chapter 4 -
, lists all the drive ratings and specifications.
Upon completing the instructions in this guide, the Drum HV (High Voltage) servo drive should
be successfully mounted and installed. From this stage, you need to consult higher level Elmo
documentation in order to set up and fine-tune the system for optimal operation:
•
The SimplIQ Software Manual, which describes the comprehensive software used with the
Drum HV (High Voltage)
•
The SimplIQ Command Reference Manual, which describes, in detail, each software
command used to manipulate the Drum HV (High Voltage) motion controller
•
The Composer Software Manual, which includes explanations of all the software tools that
are part of Elmo’s Composer software environment
