4.4. Power Ratings for the 800 V Type
Feature Units 8/800 12/800 R11/800 R16/800
Minimum supply voltage VDC S option in P/N: 95+
Nominal supply voltage VDC 560 for 400 VAC
680 for 480 VAC
Maximum supply voltage VDC 780
Maximum continuous power
output
kW 5 7.5 7 10
Efficiency at rated power (at
nominal conditions)
% > 98
Auxiliary supply voltage
option
VDC 18 V to 30 V
Only for Control Supply S option Model
Auxiliary power supply VA ≤5 VA without external loading
≤7 VA with full external loading
Continuous current limit (Ic)
Amplitude sinusoidal/DC
trapezoidal commutation
A 8 12 11 16
Sinusoidal continuous RMS
current limit (Ic)
A 5.7 8.5 7.8 11.3
Peak current limit A 2 x Ic No peak
Weight g (oz) 650 g (22.9 oz) for standard L shape
1100 g (38.8 oz) for L shape fins and fan
Dimensions mm
(in)
140 x 105 x 43 (5.51" x 4.13" x 1.7")
for standard L shape
Digital in/Digital out/ Analog in 6/4/1
Mounting method Panel / Wall Mounted
The following note applies to Power Ratings of both the 400 and 800 V drive types.
Note: Current rating: The current ratings of the DC Trombone are given in units of DC
amperes (ratings that are used for trapezoidal commutation or DC motors). The RMS
(sinusoidal commutation) value is the DC value divided by 1.41.
