Gold Eagle Installation Guide
MAN-G-EAGIG-EC (Ver. 1.000)
||Physical Specifications
9
4.2. Physical Specifications
Feature
Units
All Types
Weight
g (oz)
700 g (24.7 oz)
Dimensions
mm (in)
134 x 95 x 72 (5.3" x 3.7" x 2.84")
Mounting method
Wall/Panel Mount
4.3. Technical Data
Feature
Un
it
s
70/
60
50/
100
100/
100
R150/
100
35/
200
R60/
200
18/
400
R26/
400
Minimum supply voltage
VDC
14
46
92
Nominal supply voltage
VDC
50
85
170
340
Maximum supply voltage
VDC
59
95
195
390
Maximum continuous
power output
W
3400
4000
8000
12000
5600
9600
5600
11500
Efficiency at rated power
(at nominal conditions)
%
> 99
Max output voltage
97% of DC bus voltage at f=22 kHz
V
L
Logic supply input
voltage
VDC
14 to 72
V
L
Logic supply input
power
VA
≤ 4 VA without external loading of 5V (Encoders)
≤ 6 VA with full external loading of 5V (2 encoders)
Amplitude sinusoidal/DC
continuous current
A
70
50
100
150
35
60
18
26
Sinusoidal continuous
RMS current limit (Ic)
A
50
35
70
106
25
42
12.7
18.4
Peak current limit
A
2 x Ic 2 x Ic
2 x Ic No Peak 2 x Ic
No Peak 2 x Ic No Peak
Table 1: Power Ratings
Notes:
The current ratings of the Gold Eagle are given in units of DC amperes (ratings
that are used for trapezoidal commutation or DC motors). The RMS (sinusoidal commutation)
value is the DC value divided by 1.41.
The “Minimum supply voltage” of the XXX/100 is 14 VDC, to allow operation at 24 VDC with
the 100 VDC products.
The VL of the XXX/100 is 14 – 72 VDC, to improve the ruggedness of the products and to allow
more flexibility with the VL.
