Page 8: Technical information
Gold Eagle Installation Guide
MAN-G-EAGIG-EC (Ver. 1.000)
||Environment Conditions
8
Chapter 4:
Technical Information
This chapter describes the relevant technical data applicable to the Gold Eagle servo drive. For
further details of the Gold ExtrIQ Line EMC and Safety standards, refer to the MAN-G-Panel
Mounted Drives Hardware Manual Chapter 15: Gold Line Standards.
4.1. Environment Conditions
The ExtrIQ products are designed, manufactured and tested to meet extreme environmental
conditions. The ExtrIQ durability is qualified, verified and tested according to the most severe
environmental, EMC and safety standards exceeding the traditional and senior military
Standards.
The ExtrIQ series of drives support the following extended environmental conditions.
Feature
Operation Conditions
Range
Ambient
Temperature
Range
Non-operating conditions
-50 °C to +100 °C (-58 °F to 212 °F)
Operating conditions
-40 °C to +70 °C (-40 °F to 160 °F)
Temperature
Shock
Non-operating conditions
-40 °C to +70 °C (-40 °F to 160 °F)
within 3 min
Altitude
Non-operating conditions
Unlimited
Operating conditions
-400 m to 12,000 m (-1312 to 39370 feet)
Maximum
Humidity
Non-operating conditions
Up to 95% relative humidity
non-condensing at 35 °C (95 °F)
Operating conditions
Up to 95% relative humidity non-
condensing at 25 °C (77 °F), up to 90%
relative humidity non-condensing at 42 °C
(108 °F)
Vibration
Operating conditions
20 Hz to 2,000 Hz, 14.6g
Mechanical
Shock
Non-operating conditions
±40g; Half sine, 11 msec, 3 per direction
(overall 18)
Operating conditions
±20g; Half sine, 11 msec, 3 per direction
(overall 18)
