General wiring diagram (e3f and e4f) – Elkhart Brass Unibody Valve User Manual
Page 71
71
800.346.0250 • www.elkhartbrass.com
General Wiring Diagram (E3F and E4F)
1. Controller harness
2. Sensor/solenoid harness
a. Pressure only (UBEC2 only)
b. Pressure and flow (UBEC3 only)
3. Pressure sensor
4. Flow sensor or air solenoid
5. Secondary controller harness (Datalink)
Figure 50. General Wiring Diagram (E3F and E4F)
3
4
2
5
External inputs
wire not supplied
Remote inputs
UBEC Controller
J1939 Data bus
Input Device Options
CAN bus wire
not supplied
12/24 VDC
power supply
Motor
leads
1
