8
Monitor Wiring –
 Place a 10A fuse between the red lead (pin C) of the monitor and a switched positive power
lead on the vehicle. Attach the black lead (pin A) from the monitor base to the vehicle ground.
 The white lead (pin B) is for an optional “Stow Indicator” which could be attached to a relay or
LED supplied by the OEM. The circuit switches in a ground when the monitor is in a non-stowed
position.
 All control functions are sent to the monitor via an encoded RF signal from the RF controller,
and no control wiring is needed.
 The 8294-07 has a serial position feedback display. On the Deutsch DTM04-3P connector, the
red wire supplies power, the black wire supplies ground, and the third pin is a plug. On the
Deutsch DT04-2P connector, the blue wire is signal for the position feedback display, and the
black wire is ground.
Panel Mount RF Controllers –
 Using the Panel Mount RF Controller template in the Component Mounting Templates section,
mark the panel cutout and mounting screw locations.
 Cut a rectangular clearance opening and drill four (4) 7/32” holes.
 Insert fixed RF controller case through the panel cutout. Secure the unit to the panel with four (4)
#10-32 screws. The length of the screws should be the panel thickness plus 3/16”. The screws
supplied are ¼” in length. Apply Loctite 242 or equivalent to screw threads before tightening
them.
 Place a 1A fuse between the red lead of the RF controller and a switched positive power lead on
the vehicle. Attach the black lead from the monitor base to the vehicle ground.
 All control functions are sent to the monitor via an encoded RF signal from the RF Controller.
