Ii. system features, System features, Ii. s – Elkhart Brass Scorpion 8394-04 User Manual
Page 5
2
II. S
YSTEM
F
EATURES
OPTIONAL
ELECTRIC NOZZLES
PRESSURE
GAUGE
USER SELCTABLE STOPS
TO ADJUST VERTICAL
TRAVEL LIMITS
HIGH TORQUE
MOTORS FOR
RELAIBLE AND
SMOOTH OPERATION
VANED
WATERWAY TO HELP
REDUCE FRICTION LOSS
MANUAL OVERRIDES
4” 150# ANSI FLANGE
USER SELCTABLE STOPS
TO ADJUST HORIZONTAL
TRAVEL LIMITS
Figure 1
8294-04 Scorpion
and SM-2000E Nozzle
