13
¾
Strip off outer jacket of cable to a length of 4 inches. Pull cable back through strain
relief so that just 1/4" of the cable jacket protrudes into the box. Tighten strain relief
fitting nut securely.
¾
Strip 1/4" of insulation off seven of the nine individual 18AWG conductors. Violet
and black will not be used. Clip them off as close to the end of the cable jacket as
possible. Attach an insulated (red) fork style crimp connector to each of the remaining
seven wires.
¾
Attach the seven wires to the terminal strip in the bottom of the box per Table 1.
Label
Wire Color
Not used
Black
+12V Red
Not used
Violet
STRT Orange
FOG Green
UP White
DOWN Blue
LEFT Yellow
RIGHT Brown
Table 1 - Secondary Harness Wire Descriptions
¾
Make sure gasket in box lid is free of dirt, cuts, or other damage. Reattach lid to box
and tighten four screws securely.
5.
81242001 Receptacle for Hand-Held Remote Control to (81480001 Center-
Stow or 81480011 Left-Stow) Relay Control Module
¾
If receptacle is mounted within 24 inches of the 81339001 switch control module,
insert 36805000 wye harness between the Packard connector of the switch control
module and the wiring harness leading to the relay box. Attach connector on
81242001 receptacle harness to mating connector on extra leg of wye harness.
¾
See wiring diagram for required harness configurations for various combinations of
single and multiple switch modules and hand held remote control receptacles.
6. 81466001 Auxiliary Battery to (81480001 Center-Stow or 81480011 Left-
Stow) Relay Control Module
¾
Loosen nut on strain relief fitting on battery box and remove yellow cable. Remove
cap from battery receptacle on relay box. Attach 90
° molded-end cable connector to
relay box, and route cable to battery box, securing cable to structural members with
cushioned clamps.
¾
Remove lid from battery box. Cut cable to length, allowing nine inches for insertion
into box. Strip off eight inches of outer jacket, and insert cable through strain relief
fitting into box. Tighten fitting nut securely.
